UBNT U7-Industrial

Podrobnosti

IP67 industrial WiFi 7 access point with extended-temperature operation, integrated high-gain directional RF system with adjustable isolation and beamwidth control.
Technical Specifications
Overview
Dimensions
Device: 170 × 103 × 41.2 mm (6.7 × 4.1 × 1.6") Ball mount installed: 170 × 103 × 107.6 mm (6.7 × 4.1 × 4.2") Adjustable reflectors installed: 177.6 x 299.7 × 177.8 mm (7 x 11.8 × 7") Omnidirectional antennas installed: 341.8 × 103 × 107.6 mm (13.5 × 4.1 × 4.2")
WiFi Standard
WiFi 7
Spatial Streams
4
Coverage Area
465 m2 (5,000 ft2)
Max. Client Count
200+
Uplink
2.5 GbE
Mounting
Wall, Pole (Mounts included)
Weatherproofing
IP67
Power Method
PoE
Performance
MIMO
5 GHz
2 x 2 (DL/UL MU-MIMO)
2.4 GHz
2 x 2 (DL/UL MU-MIMO)
Max. Data Rate
5 GHz
4.3 Gbps (BW240)
2.4 GHz
688 Mbps (BW40)
Antenna Gain
5 GHz
Directional internal (Built-in): 10 dBi, 95° x 45° Directional internal (Reflector Wide Angle): 11 dBi, 70° x 45° Directional internal (Reflector Narrow Angle): 12 dBi, 55° x 45° External omni: 6 dBi, 360° x 45°
2.4 GHz
Directional internal (Built-in): 8 dBi, 100° x 45° Directional internal (Reflector Wide Angle): 9 dBi, 80° x 45° Directional internal (Reflector Narrow Angle): 10 dBi, 65° x 45° External omni: 5 dBi, 360° x 45°
Max. TX Power
5 GHz
24 dBm
2.4 GHz
23 dBm
Features
Wireless Meshing
Yes
Band Steering
Yes
802.11v BSS Transition Management
Yes
802.11r Fast Roaming
Yes
802.11k Radio Resource Management (RRM)
Yes
Advanced Radio Management
Yes
Real-Time Spectral Analysis
Yes
Passpoint (Hotspot 2.0)
Yes
Captive Hotspot Portal
Custom Branding Landing Page
Yes
Voucher Authentication
Yes
Payment-Based Authentication
Yes
External Portal Server Support
Yes
Password Authentication
Yes
Guest Network Isolation
Yes
Private Pre-Shared Key (PPSK)
Yes
WiFi Speed Limiting
Yes
Client Device Isolation
Yes
WiFi Schedules
Yes
RADIUS over TLS (RadSec)
Yes
Dynamic RADIUS-assigned VLAN
Yes
Hardware
Max. Power Consumption
13W
Supported Voltage Range
42.5–57V DC
Networking Interface
(1) 2.5 GbE RJ45 port
Weight
Device: 577 g (1.3 lb) Ball mount: 163 g (5.8 oz) Reflector antenna set: 500 g (1.1 lb) Omni antenna set: 52 g (1.8 oz)
Wind Loading
97.3 N at 200 km/h (21.9 lbf at 125 mph)
Pole Mount Diameter
1–2.5" (25–63.5 mm)
Management
Ethernet
Enclosure Material
UV-stabilized polycarbonate, aluminum alloy
Mount Material
Aluminum alloy
LEDs
System
(4) Blue: signal (1) White/Blue: indicator
Ambient Operating Temperature
-40 to 70° C (-40 to 158° F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
Yes
Certifications
CE, FCC, IC
