Typ aktivního prvku:AP (Access Point), MU-MIMO; Frekvenční pásmo (GHz):2,4, 5, 2,4 + 5 (Dual Band), 6; Podporované standardy:802.11ax, 802.11b/g, 802.11b/g/n, 802.11b, 802.11a, 802.11a/n, 802.11g, 802.11n, 802.11ac, 802.11be; Zabezpečení:WEP 64bit, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WPA3; Typ antény:Integrovaná; Použití:Venkovní

Vaše cena:
Dostupnost: Skladem 2 ks
Kód:
324516
P/N:
EAP772-Outdoor
Záruka:
60 Měsíc(ů)
Výrobce:
TP-link
Zástupce v EU:
EAN:
1210002602280
Vyhledávací název:
TP-Link EAP772-Outdoor-venkovní OMADA WiFi7 AP (BE9300,2,4GHz/5GHz/6GHz,1x2,5GbELAN,1xPoE-in)
Porovnat produkt

Podrobnosti

TP-Link EAP772-Outdoor

Omada třípásmový všesměrový BE9300 vnitřní/venkovní Wi-Fi 7 přístupový bod

  • Třípásmová venkovní Wi-Fi 7 se šesti streamy: Až 9,3 Gb/s.
  • Pásmo 6 GHz odemčené pomocí AFC: AFC umožňuje venkovní použití pásma 6 GHz. ? (V ČR/SR je 6 GHz pásmo povoleno pouze uvnitř budov)
  • Skutečné třípásmové všesměrové pokrytí: Doporučené pokrytí 300 m2 *
  • Profesionální design hardwaru: Špičková odolnost IP68, 1× 2,5G PoE+ port, 2,4 GHz antény s duální polarizací.
  • Snadné a rychlé nastavení: Montáž na zeď/sloup; Omada SDN pro nastavení jedním kliknutím
  • Pokročilé funkce: Centralizovaná správa, mesh a plynulý roaming. §

Stránky produktu: https://www.omadanetworks.com/cz/business-networking/omada-wifi-outdoor/eap772-outdoor/

Technické specifikace

HARDWARE FEATURES
Interface 1× 2.5G Ethernet (RJ-45) Port (Support 802.3at PoE)
Button Reset
Power Supply • 802.3at PoE
Max. Power Consumption 21.5W (for PoE)
Dimensions ( W x D x H ) 9.1× 8.2 × 2.8 in (230 × 207.5 × 69.7 mm)
Antenna • 2.4 GHz: 2× 4 dBi
• 5 GHz: 2× 6 dBi
• 6 GHz: 2× 6 dBi
GNSS L1 (1575.42 MHz) receiver, supporting GPS, Galileo, GLONASS, and BeiDou signals
Receive sensitivity: -164dBm (tracking)
GPS antennas: Integrated 3dBi omnidirectional antennas
Bluetooth BLE 5.2
Weatherproof Enclosure IP68
Mounting Pole/Wall Mounting (Kits included)
WIRELESS FEATURES
Coverage 300m2 (3,200ft2) Recommended Omnidirectional Coverage
Concurrent Clients 380+**
Wireless Standards IEEE 802.11be/ax/ac/n/g/b/a
Frequency 2.4 GHz, 5 GHz, 6 GHz
Signal Rate 688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz) + 5765 Mbps (6 GHz)†
Wireless Functions • 4k-QAM
• OFDMA
• Multiple SSIDs: 24 (8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS (WMM)
• MU-MIMO
• MLO
• 320MHz
• Omada Mesh§
• Seamless Roaming(802.11k/v/r)§
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client
• Static IP/Dynamic lP
Wireless Security • Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE
Transmission Power • CE:
Indoor Mode: < 20 dBm (2.4 GHz, EIRP);, < 23 dBm (5 GHz, band 1 & band 2, ElRP), < 28 dBm (5 GHz, band 3, EIRP); <23dBm (6 GHz, EIRP)
Outdoor Mode: < 20 dBm (2.4 GHz, EIRP); < 28 dBm (5 GHz, band 3, EIRP)
• FCC:
Indoor Mode: < 25 dBm (2.4 GHz); < 25 dBm (5 GHz); < 25 dBm (6 GHz)
Outdoor Mode:< 25 dBm (2.4 GHz); < 25 dBm (5 GHz); < 25 dBm (6 GHz)
Management Features
Omada App Yes
Centralized Management • Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
Cloud Access Yes. Require the use of an Omada controller.
Email Alerts Yes
Management MAC Access Control Yes
SNMP v1, v2c
System Logging Local/Remote Syslog Yes
SSH Yes
Web-based Management Yes
L3 Management Yes
Multi-site Management Yes
Management VLAN Yes
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller
OTHERS
Certification CE, FCC, RoHS
Package Content • Access Point EAP772-Outdoor
• Waterproof Kit
• Mounting Kits
• Installation Guide
System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Environment • Operating Temperature: -30–70 ? (-22–158 ?)
• Storage Temperature: -40–70 ? (-40–158 ?)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
